The Pro-Stance 52″ is just what you’ve been searching for. It allows for all-day comfort combined with high-quality cuts and increased durability. The dual height adjustment system was designed with both a traditional hand lever and a foot lever to lift and adjust the deck, perfect for smaller operators that may struggle with hand lever lifts.
Step up to greatness with this legendary unit. The ZT-3400 integrated transmission boasts an industry leading 1.125 inch axle that can take on the heaviest of loads. Its new look is constructed from 7-gauge steel that will deliver years of solid, Gravely performance.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
| Specifications | |
|---|---|
| Model | AGU994162 |
| Engine Manufacturer | Kawasaki FX730V |
| Horsepower / Displacement | 23.5 HP / 726 CC |
| Drive System | Hydro-Gear ZT-3400 Transaxles HTG |
| Fuel Capacity | 33.9 L |
| Ground Speed | 14.4 KM/H Forwards, 6.4 KM/H Backwards km/h |
| Deck Size | 52" |
| Deck Material | 7 GA. |
| Deck Construction | Fabricated X-Factor 3 Deck |
| Number Of Spindles | 3 |
| Blade Tip Speed (FPM) | 18,000 FPM |
| Spindle Housing Material | Forged Aluminum |
| Spindle Bearings | Sealed Bearing |
| Deck Engagement | Ogura 2.75 Electric Clutch |
| Deck Lift System | Oval – Traditional Hand And Foot Lever |
| Cutting Width | 52 Inch |
| Cutting Positions / Height | 15 Cutting Positions / 38.1 MM – 127MM |
| Wheels Front | 13 x 6.50 – 6 Semi-Pneumatic |
| Wheels Rear | 20 x 10.50 – 8 Radial |
| Seat | N/A |
| Foldable ROPS | N/A |
| Weight | 460.4 KG |
| Length | 1540 MM |
| Width | 1409.7 MM With Chute Up, 1720.8 MM With Chute Down |
| Height | 1219.2 MM |
| Warranty | 5 Year / 1000 Hour Commercial |
