Out with the old in with the new. Gravely’s Pro-Turn EV 52″ features four swappable batteries to deliver the all-day reliable performance you need to tackle any job of any size. Its LCD display screen keeps the operator in the know with information on the battery charge, blade engagement, and even alerts if an issue needs to be resolved.
Built with next-generation wheel drives, the transaxles are driven with a brushless electric-drive motor coupled with a dual-reduction planetary gearbox. The deck has been completely redesigned and made from 7-gauge steel for better grass dispersion and solid performance for years to come.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
| Specifications | |
|---|---|
| Model | AGU997006 |
| Engine Manufacturer | 4 x 16 KWH Fusion Core Lithium Ion |
| Horsepower / Displacement | 5 KW Wheel Drive Motor / 3.5 kw Per Spindle Motor |
| Drive System | Proprietary Electric Transaxles |
| Fuel Capacity | N/A |
| Ground Speed | 12.8 KM/H Forwards, 6.4 KM/H Backwards (Low Speed), 17.7 KM/H Forwards, 8.8 KM/H Backwards (High Speed) |
| Deck Size | 52" |
| Deck Material | 7 GA. |
| Deck Construction | Fabricated X-Factor 3 Deck |
| Number Of Spindles | 3 |
| Blade Tip Speed (FPM) | 18,000 FPM |
| Spindle Housing Material | Cast Aluminum |
| Spindle Bearings | Serviceable Bottom Bearing |
| Deck Engagement | Electric DC Brushless Motors |
| Deck Lift System | N/A |
| Cutting Width | 52 Inch |
| Cutting Positions / Height | 15 Cutting Positions (38.1 MM – 127 MM) |
| Wheels Front | 13 x 6.5 – 6 Smooth |
| Wheels Rear | 22 x 10.5 – 12 Turf |
| Seat | High Back Comfort W/ Suspension |
| Foldable ROPS | Standard |
| Weight | 582.4 KG |
| Length | 2108.2 MM |
| Width | 1422.4 MM With Chute Up, 1701.8 MM With Chute Down |
| Height | 1828.2 MM With ROPS Up, 1244.6 MM With ROPS Down |
| Warranty | 5 Year / 1500 Hour Commercial / 3 Year Battery Warranty |
