Step up to greatness with Gravely’s Pro-Stance 36″, designed to impress. The dual height adjustment system was invented with both a traditional hand lever and a foot lever to lift and adjust the deck. It’s perfect for smaller operators who may struggle with traditional hand level lifts.
The suspension platform on the mower deck seamlessly absorbs vibrations for all day comfort. The Pro-Stance is the perfect blend of power and performance for all environments that demand on and off versatility during mowing sessions.
For more information on how we collect, hold, use and disclose personal information, please see our privacy policy.
Click on the images below to enlarge.
| Specifications | |
|---|---|
| Model | AGU994149 |
| Engine Manufacturer | Kawasaki FS600V |
| Horsepower / Displacement | 18.5 HP / 603 CC |
| Drive System | Hydro-Gear ZT-3100 Transaxles |
| Fuel Capacity | 22.6 L |
| Ground Speed | 12.8 KM/H Forwards, 4.8 KM/H Backwards km/h |
| Deck Size | 36" |
| Deck Material | 7 GA. |
| Deck Construction | Fabricated X-Factor 3 Deck |
| Number Of Spindles | 2 |
| Blade Tip Speed (FPM) | 18,220 FPM |
| Spindle Housing Material | Forged Aluminum |
| Spindle Bearings | Sealed Bearing |
| Deck Engagement | Ogura 2.75 Electric Clutch |
| Deck Lift System | Oval – Traditional Hand And Foot Lever |
| Cutting Width | 36 Inch |
| Cutting Positions / Height | 15 Cutting Positions / 38.1 MM – 127MM |
| Wheels Front | 11 x 4.00 – 5 Semi-Pneumatic |
| Wheels Rear | 18 x 8.50 – 8 Radial |
| Seat | N/A |
| Foldable ROPS | N/A |
| Weight | 355.6 KG |
| Length | 1511.3 MM |
| Width | 927.1 MM With Chute Up, 1244.6 MM With Chute Down |
| Height | 1219.2 MM |
| Warranty | 5 Year / 1000 Hour Commercial |
